Introduction
This topic aims to guide you through the installation of the chip "Delta SmartWave" in your Sony PlayStation 1 console.

Features
The Delta SmartWave allows your console to automatically adapt to the GPU frequency and video subcarrier based on the region of the inserted game (50Hz or 60Hz).

If you try to play an imported game (e.g., JAP) on a European (PAL) console, you may end up with a black and white screen. This is due to the incorrect timing required by the game compared to what is present in your console.
A 60Hz game (JAP or USA) should normally be played on an NTSC console.
A 50Hz game (PAL) should normally be played on a PAL console.

Thanks to the Delta PSNee (available at the ImageDelta Store >>), you can play all games on your console.
However, the console's frequency is not modified, which results in black and white images.
Some people use an RGB cable to improve the quality of the video signal.
The RGB cable will return color to your games, but will hide the frequency issue. For purists and OSSC owners, it is essential to correct this.

That's where Delta SmartWave comes in!

Through intelligent detection, the Delta SmartWave automatically adjusts the GPU frequency and video subcarrier with great precision, correcting all the previously mentioned issues.

With the combination of "Delta PSNee" + "Delta SmartWave," you will have the ultimate console—no need to own three different consoles for each region (PAL, JAP, USA).

Finally, we remind you that Delta SmartWave was designed to be soldered without cables!

Delta SmartWave est plus precise et plus intelligente que :
- PS1 MFO / MOFO (Multi Output Frequency Oscillator)
- PS1 DFO (DUAL Output Frequency Oscillator)

No need for programming or unpleasant surprises like the mods mentioned above!

Delta SmartWave is an intelligent solution that adapts to all situations, without asking any questions

Delta SmartWave: A Major Advancement Over Traditional DFO (Dual Frequency Oscillator) and MFO (Multi Frequency Oscillator)



1. An Intelligent Microcontroller for Precise Adjustments

As the name suggests, the SmartWave is “smart.” It features a microcontroller capable of automatically detecting the console version (PU-7, PU-8 early, PU-8 late, PU-18, etc.) on which it is installed. This allows it to precisely adjust its frequencies to match the technical specifications of each model, unlike DFO/MFO, which do not cover all variants, such as the PU-7 and PU-8 early.



2. Universal and Automatic Compatibility

Frequency management varies between PlayStation versions. While DFO/MFO often require modifications or are incompatible with certain models, the SmartWave automatically detects the region and console characteristics, adjusting to the correct frequency (PAL 50Hz or NTSC 60Hz) without manual intervention.



3. An Ultra-Precise Frequency Generator

The SmartWave integrates the most precise frequency generator available to date, ensuring perfectly aligned frequencies with the original specifications of PAL and NTSC consoles. By comparison, DFO/MFO use approximate frequencies, often with high decimal values. While functional, they are significantly less optimized.



4. Easy Installation and Optimized Performance

Unlike DFO/MFO, which may require complex manual configurations, the SmartWave is easy to install, without additional wiring (*one wire required for PU-7 and PU-8 EARLY). Once in place, it operates autonomously, offering unmatched precision and eliminating video synchronization issues or black-and-white display problems.



The Issue of Regional Frequencies

When a PAL PlayStation is used with an NTSC-J or NTSC-U/C game and the original composite video cable, the display appears in black and white.

An RGB cable can restore color, but this only solves part of the problem…

The real issue lies within the GPU (Graphics Processing Unit) and the video subcarrier:

1. The console’s GPU is clocked differently depending on the PlayStation’s original region.

2. PlayStations use region-specific crystals (PAL or NTSC), which can lead to underclocking or overclocking depending on the game being played.

This discrepancy, while subtle, is noticeable:

• The GPU and other components do not operate at their optimal frequencies.
• This can cause slowdowns or a loss of fluidity in certain games.



Why Delta SmartWave is Different ?

Delta SmartWave directly adjusts the GPU clock frequencies and the video subcarrier.

Thanks to its intelligent management system:
• It automatically detects whether the game is PAL or NTSC and adjusts frequencies accordingly.
• It restores perfectly aligned frequencies (PAL 50Hz or NTSC 60Hz), eliminating any underclocking or overclocking.



In Summary

Delta SmartWave vastly outperforms DFO and MFO in terms of precision, compatibility, and intelligent frequency adjustment. It offers an innovative plug-and-play solution that adheres to the original console specifications, delivering an unmatched retro gaming experience.



- Compatible with all PlayStation versions :
ImagePAL ImageNTSC U/C ImageNTSC J ImageNTSC J (ASIA)
SCPH-1002
SCPH-5502
SCPH-5552
SCPH-7002
SCPH-7502
SCPH-9002
SCPH-1001
SCPH-5001
SCPH-5501
SCPH-7001
SCPH-7501
SCPH-9001
SCPH-1000
SCPH-3000
SCPH-3500
SCPH-5000
SCPH-5500
SCPH-7000
SCPH-7000W
SCPH-7500
SCPH-9000

SCPH-5503
SCPH-5903
SCPH-7003
SCPH-7503
SCPH-9003

Difficulty

  • Delta SmartWave
    ImageDelta Store >>

    • A Phillips screwdriver

    • A soldering iron

    • Solder

Tutorial

1 - Identification of your PlayStation console

First, locate the label underneath your PlayStation console.
On this label, identify the model of your PlayStation.



In this example, the model is “SCPH-7502”. While this reference provides important information, we need to verify the exact motherboard revision.
To do this, we will need to access your console’s motherboard.



2 - Disassembly of the PlayStation console
 !  WARNING

⚠️ WARNING! To eliminate any electrical risk, please unplug all cables from your console, press the “Power” button, and set the console aside for approximately 2 hours to allow the capacitors to fully discharge!

Below, you will find various videos.
The goal is to access the motherboard. You do not need to disassemble the console’s power supply. Please do not touch it!


3 - Identification of your PlayStation motherboard

Please identify your motherboard using the following photos :


Image ImagePU-7
PU-7 // 1-655-322-11
PU-7 // 1-655-322-13
PU-7 // 1-655-322-13A
PU-7 // 1-655-322-14
PU-7 // 1-655-322-14A
PU-7 // 1-655-322-15
PU-7 // 1-655-322-16
Image ImagePU-8 EARLY
PU-8 // 1-658-467-11
PU-8 // 1-658-467-12
PU-8 // 1-658-467-13
Image ImagePU-8 LATE
PU-8 // 1-658-467-21
PU-8 // 1-658-467-22
PU-8 // 1-658-467-23
PU-8 // 1-658-467-41
PU-8 // 1-658-467-42
Image ImagePU-16
PU-16 // 1-665-191-11
Image ImagePU-18
PU-18 // 1-664-537-11
PU-18 // 1-664-537-21
PU-18 // 1-664-537-31
PU-18 // 1-664-537-41
PU-18 // 1-664-537-52
PU-18 // 1-664-537-62
PU-18 // 1-664-537-72
PU-18 // 1-664-537-82
Image ImagePU-20
PU-20 // 1-668-413-12
PU-20 // 1-668-413-22
PU-20 // 1-668-413-32
PU-20 // 1-668-413-42
Image ImagePU-22
PU-22 // 1-671-858-11
PU-22 // 1-671-858-12
PU-22 // 1-671-858-21
PU-22 // 1-671-858-22
PU-22 // 1-671-858-32
Image ImagePU-23
PU-23 // 1-674-987-11
PU-23 // 1-674-987-21
PU-23 // 1-674-987-31
PU-23 // 1-674-987-41
PU-23 // 1-674-987-51
4 - Installation of the "Delta SmartWave"

4.1 - PU-7 Mainboard

4.1.1 - Locate the resistors marked in red and remove them (top side).
Please note that depending on your motherboard version, you should have only one of the two resistors marked in red on the left.

4.1.2 -Position your Delta SmartWave and proceed with soldering according to the following diagram:
For PU-7, an additional wire must be installed, running from the bottom side to the top side of the motherboard.
Image Image
Image Image

4.1.3 - Reassemble your console.

4.2 - PU-8 EARLY MainBoard

4.2.1 - Locate the resistors marked in red and remove them (top side).
Please note that depending on your motherboard version, you should have only one of the two resistors marked in red on the left.

4.2.2 - Position your Delta SmartWave and proceed with soldering according to the following diagram
For PU-8 EARLY, an additional wire must be installed, running from the bottom side to the top side of the motherboard.
ImageImage ImageImage

4.2.3 - Reassemble your console.

4.3 - PU-8 LATE & PU-16 Mainboard

4.3.1 - Locate the resistors marked in red and remove them (top side).
Please note that depending on your motherboard version, you should have only one of the two resistors marked in red.

4.3.2 - Locate the resistors marked in red and remove them (bottom side).
Please note that depending on your motherboard version, you should have only one of the two resistors marked in red.

4.3.3 - Position your Delta SmartWave and proceed with soldering according to the following diagram.
Image Image

4.3.4 - Reassemble your console.

4.4 - PU-18 Mainboard
4.4.1 - Remove the upper metal shield from the motherboard using your soldering iron

4.4.2 - Locate the resistor marked in red on the top side of the motherboard and remove it.

4.4.3 - Position your Delta SmartWave on the bottom side of the motherboard and proceed with soldering according to the following diagram.
Image Image

4.4.4 - Reinstall the upper metal shield on the motherboard using your soldering iron.

4.4.5 - Reassemble your console.

4.5 - PU-20 Mainboard
4.5.1 - Remove the upper metal shield from the motherboard using your soldering iron.

4.5.2 - Locate the two resistors marked in red and remove them.

4.5.3 - Position your Delta SmartWave and proceed with soldering according to the following diagram.
Image Image

4.5.4 - Reinstall the upper metal shield on the motherboard using your soldering iron.

4.5.5 - Reassemble your console.

4.6 - PU-22 Mainboard

The PU-22 requires good soldering skills to ensure a proper and secure installation.

4.6.1 - Remove the upper metal shield from the motherboard using your soldering iron.

4.6.2 - Locate the two resistors marked in red and remove them.

4.6.3 - Position your Delta SmartWave and proceed with soldering according to the following diagram.
Image Image

4.6.4- Reassemble your console.

4.7 - PU-23 Mainboard
The PU-23 requires good soldering skills to ensure a proper and secure installation.

4.7.1 - Locate the resistor marked in red and remove it :

4.7.2 - Locate the two “VIA” points marked in red.
Using a scalpel, gently scrape the VIA points, then tin them with solder using your soldering iron :
Image Image Image

4.7.3 - Locate pin 6 of the IC204 component and carefully lift it using a scalpel and a soldering iron :Image

4.7.4 - Position your Delta SmartWave and proceed with soldering according to the following diagram.
Image Image

4.7.5 - Reassemble your console.
